Most-complete Cat S61 Specs

Main Camera
Selfie Cam
Key Specs
Processing featuresQualcomm Snapdragon 630 CPU spread over an octa-core layout at 2.2GHz with a 4GB RAM
Display details423.84DPI 5.2-inch display with a resolution of 1920 x 1080 pixels
Imaging16-megapixel (main cam with a separate Lepton-module FLIR cam for thermal imaging) main / 8-megapixel selfie / 3840 x 2160 (1280 x 720 for thermal camera)-pixel video recording
Release dateSecond quarter 2018

Camera Details
Camera Resolution16-megapixel (main cam with a separate Lepton-module FLIR cam for thermal imaging)
Camera flashDual LED
Camera OptionsLaser-assisted area and distance measurement (up to 10m)
Camera Features
  • FLIR MSX image resolution (for thermal cam)
  • 400 degrees Celsius maximum temperature reading (for thermal camera)
Max Video Resolution3840 x 2160 px (1280 x 720 for thermal camera)
Selfie Cam Resolution8-megapixel
Display size5.2 inches
Display dots per inch423.84 DPI
Touch-ScreenCapacitive (with gloves-on and wet-finger touch input)
Display Resolution1920 x 1080 px
Display's superficy11.55 square inches
Display's superficy (metric)293.37 square mm
Display finishCorning Gorilla Glass 5
Display total pixels2073600
Processing Power
Operating SystemAndroid 8.0 Oreo (with guaranteed upgrade to Android P)
ProcessorQualcomm Snapdragon 630
CPU Cores8
Processor Speed2.2GHz
Physical Features
RuggedMIL-SPEC 810G (drop-proof from up to 1.8m), IP68 (dust- and waterproof)
Available colorsBlack
4G NetworksLTE Cat 13
SIM card typeNano SIM
Wi-Fi (2.4GHz/5GHz dual-band)
Bluetooth Technology5.0
Storage Memory
Memory ExpansionMicroSD
Battery Life
Battery Power4500mAh
mAh per display square in.390mAh/sqrin.
Charging systemQC4.0
General Specs
Special features
  • Curated app catalogue for rugged device users
  • VoLTE
  • VoWiFi
Sequel toCat S60
Other features
SensorsIndoor air quality/humidity
Included softwareMyFLIR app (with thermal image live-streaming)
Location servicesEnhanced GPS
FinishAluminium die-cast frame


The S61 features an indoor air quality sensor that enables users to detect harmful compounds within a certain work site, while it is made resistant to drops from up to 1.8 meters and impervious to liquids by its MIL-SPEC-810G and IP68 rugged ratings accordingly. Besides, it also comes with a 4500mAh battery power, which is a huge leap from its S60 predecessor's 3800mAh-only capacity.
