79 Important TCL Plex Specs

Main Camera
Selfie Cam
Our Score: 86%
Key Specs
Release dateNov 30, 2019

Camera Details
Camera Resolution48-megapixel (combined with 16- and 2-megapixel sub-cams)
Camera flashDual single-tone LED
Camera Options
  • Burst shot
  • Dark shot
  • Depth bokeh
  • Google Lens
  • Night mode
  • Panorama
  • Pro mode
  • Super Night Mode
  • Super Resolution
  • Super slow-motion
  • Time-lapse
Camera Features
  • Anti-blur
  • Anti-shaking
  • Auto zoom
  • Autofocus
  • IMX582 + S5K3P9 + OV02K sensors
  • Photo filters
  • Scene detection
  • Wide-angle distortion correction
Camera ApertureF/1.8 (for main cam, f/2.4 for 16MP cam, f/1.8 for 2MP cam)
Camera pixel size0.8 microns (for main cam, 1-micron for 16MP cam, 2.9-micron for 2MP cam)
Camera angle123 ° (for 16MP wide-angle cam, 79 degrees for main cam, 77 degrees for 2MP cam)
Video recorder featuresGyro-assisted video stabilization, Low-light video
Max Video Resolution3840 x 2160 px
Video frames per second960 (960/240/120fps for slow-motion, 30fps for standard videos)
Selfie Cam Resolution24-megapixel (fixed focus)
Pixel size0.9
Selfie FeaturesBokeh, Face Beautification, OV24B image sensor, photo filters
Selfie flashLCD flash
Selfie cam angle78.2
Max front-cam Video Resolution1920 x 1080
Front-cam frames per second30
Display size6.5 inches (actual diagonal size is 6.53 inches)
Display dots per inch395 DPI
Display aspect ratio19.5:9
Display Resolution2340 x 1080 px
Display's superficy16.05 square inches
Display's superficy (metric)407.67 square mm
Display total pixels2527200
Display featuresDotch display design, Pixelworks Visual Processor, NXTVISION technology
Processing Power
Operating SystemTCL UI (based on Android 9.0 Pie)
ProcessorQualcomm Snapdragon 675
CPU Cores8 (Dual Kryo 460 Gold + Hexa Silver)
Processor SpeedDual 2GHz (+ Hexa 1.7GHz)
Physical Features
Weight (grams)192g
Thickness (metric)7.99 mm
Width (metric)76.56 mm
Height (metric)162.2 mm
Grams per cubic cm0.19 g/cu cm
Headset Jack3.5mm
Available colors
  • Obsidian Black
  • Opal White
Included Accessories
  • Protective case
  • Screen film
4G NetworksLTE Cat 6
Maximum data rate400Mbps
Maximum uplink data rate75Mbps
SIM card typeNano SIM (4FF -- Single- and Dual-SIM models are available)
Wi-Fi802.11 b/g/n/a/ac (2.4GHz/5GHz)
Wi-Fi Direct
Bluetooth Technology5.0
USB classType-C USB 2.0
Mobile hotspot
Storage Memory
Memory ExpansionMicroSD
Expansion LimitUp to 256GB
Battery Life
Stand-by Time396hours
Talk Time720minutes
3G Talk Time1500minutes
4G Talk Time990min.
Battery Power3820mAh
mAh per gram20 mAh/g
mAh per mm thick478 mAh/mm of thickness
mAh per display square in.238mAh/sqrin.
Talk minutes per Ah188min./Ah
Battery charging time105 hours
Charging systemQuick Charge 3.0
Music / Multimedia
Audio file formatsAAC+, Enhanced AAC+, AAC LC, AMR-NB, AMR-WB, FLAC, MP3, MIDI, Vorbis, PCM/WAVE
General Specs
Phone lockFace Key
Manufacture product IDT780H
Other features
SensorsRGB light, Accelerometer, Gyro, Proximity
Special keysSmart Key
Included softwareGoogle Assistant
Location servicesA-GPS
Noise cancellation system
Sound QualityHD voice, VoLTE, VoWifi (optional)
Number of microphones2
Fingerprint detector (rear)
FinishDual-sided glossy glass + Black holographic film + OPVD film (Obsidian variant), Dual-sided glossy glass + Micro S texture + gradient OPVD film (Opal variant)


Also known as TCL T780H.
